300 V MULTICORE CABLES





300 V MULTICORE CABLES



 H03VV-F  H03VVH2-F  TS 9760 HD 21.5 S3 - VDE 0281-5 HD 21.5 S3  -30 / +70°C
 H03V2V2-F  H03V2V2H2-F  TS HD 21.12 S1 - VDE 0281-12 HD 21.12 S1  -30 / +90°C
 H03V2V2-F 105°C  H03V2V2H2-F 105°C  TS HD 21.12 S1 - VDE 0281-12 HD 21.12 S1  -40 / +105°C



Construction



 Multicore flexible cables with fine stranded copper conductors, operating temperature 70;90;105°C  alternatives PVC insulation and sheat.



Aplications



 Used in covered and dry places as connetcion cables where the mechanical stresses exist unclearly.



 1-Fine stranded, tinned or annealed copper conductors

 2-PVC insulation (-30/+70°C ; -30/+90°C ; -40/+105°C ) alternatives

 3-PVC sheath (-30/+70°C ; -30/+90°C ; -40/+105°C ) alternatives



Rated

 Cross-

 Section

Nominal

Wall

 Thickness of

Insulation

Nominal

Wall

 Thickness of

Sheath

Overall

 Diameter of

Cable

(approx.)

 Max. DC Resistance

at 20 °C

Net Weight (approx.)

Cu

 Faktor

1000m

Current

Carrying

 Capacity in Air

(at 30°C, max.)

Tinned Plain
( mm² ) ( mm ) ( mm ) ( mm ) ( Ohm / km ) ( kg / km )   ( A )

H03VVH2-F / H03V2V2H2-F / H03V2V2H2-F 105°C   300 / 300 V
2 x 0,50 0,50 0,60 3,20 x 5,10 40,10 39,0 30,00 9,40 3
2 x 0,75 0,50 0,60 3,40 x 5,50 26,70 26,0 37,00 14,00 6

H03VV-F / H03V2V2-F / H03V2V2-F 105°C   300 / 300 V
2 x 0,50 0,50 0,60 5,10 40,10 39,0 35,00 9,40 3
2 x 0,75 0,50 0,60 5,40 26,70 26,00 45,00 14,00 6
3 x 0,50 0,50 0,60 5,40 40,10 39,0 43,00 14,10 3
3 x 0,75 0,50 0,60 5,80 26,70 26,0 55,00 21,00 6
4 x 0,50 0,50 0,60 5,90 40,10 39,0 52,00 18,80 3
4 x 0,75 0,50 0,60 7,30 26,70 26,0 66,00 28,00 6
